Zakup Scania G500

38000 kg

Please provide reference number upon request: 21046

See ats.no/en/item/21046 for more images.

Chassis Specifications:

Model: Scania G 500 B8x4*4NB * Engine: DC13 165 Euro 6, 500 hp / 2550 Nm, XPI injection and SCR exhaust after-treatment

• Gearbox: GRSO905R, 12-speed with range/split, crawler gear, overdrive and retarder
• Gearbox Control: Opticruise automatic gear shifting (Standard, Power, Off-road programs)
• Chassis number: YS2G8X40002175173
• Dimensions: Length 10,155 mm, width 2,540 mm
• Wheelbase: 4,150 mm
• Gross Weight: 38,000 kg, payload 15,725 kg
• Suspension: Air suspension on all axles
• Rear Axle: RBP735 + RP735 with hub reduction, ratio 4.05:1

Power Take-Off (PTO): * ED120P engine-mounted for hydraulic pump

• EG662F gearbox-mounted (rear)
• EK730P flywheel-mounted (position 12 o’clock, 1:1 ratio)

Cabin: CG17N Medium sleeper cab with air suspension

Air Conditioning: Automatic climate control

Brakes: EBS with disc brakes on all axles, retarder (3500 Nm)

ADR Approval: Types FL and EX/III

Fuel Tank: 350 litres aluminium (left side)

AdBlue Tank: 80 litres (60 litres usable)

Body Specifications:

Type: Rigual CL3644D Vacuum and Jetting Combination Truck * Tank Material: Stainless steel

• Capacity: Total 18,000 litres
• Main tank divided into: 10,000 + 3,000 litres for sludge
• 5,000 litres clean water in stainless side tanks
• Vacuum Pump: HIBON VTB 820 XL lobe pump
• Vacuum capacity: -0.9 bar, 2674 m³/hour
• High-Pressure Pump: URACA P3-45
• Working pressure: 10–200 bar, automatic regulation
• Hose Reel (rear hatch): Two-part reel
• Large side: 150 m x 1" diameter hose
• Small side: 70 m x ½" diameter hose
• Reel designed and manufactured by NMT in Sweden
• Control System: PLC-based with display
• Remote Control: One large and one small unit
• Hydraulics: Three separate hydraulic circuits
• Cooling System: Temperature-monitored with automatic control
• Suction Boom: For hose positioning, designed and built by NMT in Sweden

Valves: * Rear: 4" acid-resistant stainless steel ball valves (JF&FR), remote controlled

• Side: 5" acid-resistant stainless steel ball valves (JF&FR), for direct filling of front tank

Safety Systems: * Primary and secondary shut-off with cyclone filter

• Safety valves for both vacuum and pressure
• Automatic overload protection
• Rear door safety system preventing opening under pressure/vacuum

Note: Subject to errors in listing. Chassis was delivered from Scania in 2020 but remained with the bodybuilder until first registration in March 2025.

Delivered fully approved

Km: 4000

HK: 500

Technical approved: Yes

EU-approved until: 12.03.2026

Own weight: 22200

Total Weight: 38000

Payload: 15725

Width: 254

Length: 1015,5

Euro: 6

Model: G500

Gearbox: Automatic
